Connector Options
WBT-0681 ag
WBT-0661 ag
WBT-0610 ag
WBT-0681 cu
WBT-0661 cu
WBT-0610 cu
WBT-0645
Basic Electrical Specifications
TriFocal-X
DUT: TFX 2.5m terminated with WBT-0660-Cu spades
| (Cp) parallel capacitance: | 1,150.0 pF @ 20 kHz |
| (Ls) series inductance: | 0.543 µH @ 20 kHz |
| (Rdc) dc loop resistance: | 0.014 Ω |
| (Xt) total reactance: | 0.068 Ω @ 20 kHz |
Frequency response ± 0.5 dB:
|
|
| Crosstalk Low-Mid 20 - 100 Hz: | < -98 dB |
| Crosstalk Low-Mid 200 Hz - 1 kHz: | < -79 dB |
| Crosstalk Low-Mid 1 kHz - 30kHz: | < -59 dB |
| Crosstalk Mid-High 20 - 100 Hz: | < -99 dB |
| Crosstalk Mid-High 200 Hz - 1 kHz: | < -80 dB |
| Crosstalk Mid-High 1 kHz - 30 kHz: | < -60 dB |
TriFocal X
TriFocal cables are a testament to Kimber Kable's manufacturing processes and the unparalleled pursuit of excellence. Comprised of hundreds of individual components per pair of cables the TriFocal-X is formatted in seven layer, poly-concentric geometry. Interaction between “High,” “Mid,” and “Low” frequency circuits are dramatically lower than other internal “tri-wire” cables. RF and EMI problems have been identified and solved using proprietary balanced Kimber Kable technologies. Your tri-wireable speakers never had it so good.
