Connector Options
Spade
SBAN
Postmaster 25
Postmaster 33
Postmaster N3
Basic Electrical Specifications
8PR
DUT: 8PR 2.5m bare wire ends.
| (Cp) parallel capacitance: | 742.0 pF @ 20 kHz |
| (Ls) series inductance: | 0.459 µH @ 20 kHz |
| (Rdc) dc loop resistance: | 0.021 Ω |
| (Xt) total reactance: | 0.057 Ω @ 20 kHz |
| Frequency response ± 0.5 dB: dc - 50 kHz | |
8PR
4PR’s big brother in every way. Better bass, detailed midrange and smooth upper octaves will let 8PR happily live in your system for years to come. Eight conductors per polarity yield 10 AWG (4.5117mm²) aggregate conductor size for longer runs or demanding loads.
