Connector Options
Ultratike
XLR
Basic Electrical Specifications
Tonik
DUT: Tonik 1m terminated with Ultratike RCA type connectors.
| (Cp) parallel capacitance: | 52.0 pF @ 20 kHz |
| (Ls) series inductance: | 0.772 µH @ 20 kHz |
| (Rdc) dc loop resistance: | 0.055 Ω |
| (Xt) total reactance: | 0.098 Ω @ 20 kHz |
| Frequency response ± 0.5 dB dc - 2.8 MHz | |
Tonik Balanced
DUT: Tonik 1m terminated with XLR type connectors.
| (Cp) parallel capacitance: | 43.9 pF @ 20 kHz |
| (Ls) series inductance: | 1.05 µH @ 20 kHz |
| (Rdc) dc loop resistance: | 0.0961 Ω |
| (Xt) total reactance: | 0.131 Ω @ 20 kHz |
| Frequency response ± 0.5 dB dc - 2.8 MHz | |
Tonik
Like the first tone of a scale, the Tonik interconnect provides the foundation of truly accurate performance and value. Through the use of Kimber Kable's legendary tri-braid field geometry, VariStrand™, Ultrapure copper conductors and our special recipe PE dielectric, the Tonik allows music to flow with power, smoothness and harmonic richness. Tonik single-ended uses our Ultratike™ RCA type connector. Tonik balanced features "studio grade" XLR connectors with silver plated contacts.
